沙迪克打孔机用眼模

  • TSG-NEW-R 3563746 New Type (Stainless case Ruby insert) Ts guide for Sodick Small Hole Drilling Mechine
  • TSG-NEW-R 3563746 New Type (Stainless case Ruby insert) Ts guide for Sodick Small Hole Drilling Mechine
  • TSG-NEW-R 3563746 New Type (Stainless case Ruby insert) Ts guide for Sodick Small Hole Drilling Mechine
TSG-NEW-R 3563746 New Type (Stainless case Ruby insert) Ts guide for Sodick Small Hole Drilling MechineTSG-NEW-R 3563746 New Type (Stainless case Ruby insert) Ts guide for Sodick Small Hole Drilling MechineTSG-NEW-R 3563746 New Type (Stainless case Ruby insert) Ts guide for Sodick Small Hole Drilling Mechine

TSG-NEW-R 3563746 New Type (Stainless case Ruby insert) Ts guide for Sodick Small Hole Drilling Mechine

  • Ref No.: TSG-NEW-R-020
  • OEM No.: 3563746 3562243
  • Size: OD=10mm,ID=0.20mm,L=23mm
  • Brand: Sodick
  • 产品描述: TSG-NEW-R 3563746 New Type (Stainless case Ruby insert) Ts guide for Sodick Small Hole Drilling Mechine,EDM Consumables,Power EDM
  • 在线订购   邮箱
产品详情:

Sodick TS Guide

New Type (Stainless case Ruby insert)

Available ID=0.1mm-5.0mm

Body OD=10.0mm

Length L=23mm


Model NO.

ID (mm)

OEM NO.(5um)

OEM NO.20um

TSG-NEW-R-010

Φ0.10mm

-

-

TSG-NEW-R-015

Φ0.15mm

-

-

TSG-NEW-R-020

Φ0.20mm

3563746

3562243

TSG-NEW-R-025

Φ0.25mm

3564451

3561845

TSG-NEW-R-030

Φ0.30mm

3562590

3562016

TSG-NEW-R-040

Φ0.40mm

3562589

3562017

TSG-NEW-R-050

Φ0.50mm

3563485

3562018

TSG-NEW-R-060

Φ0.60mm

3561061

3562019

TSG-NEW-R-070

Φ0.70mm

3561062

3562020

TSG-NEW-R-080

Φ0.80mm

3561063

3562021

TSG-NEW-R-090

Φ0.90mm

3561064

3562022

TSG-NEW-R-100

Φ1.00mm

3561065

3562023

TSG-NEW-R-110

Φ1.10mm

3561066

3562024

TSG-NEW-R-120

Φ1.20mm

3561067

3562025

TSG-NEW-R-130

Φ1.30mm

3561068

3562026

TSG-NEW-R-140

Φ1.40mm

3561069

3562027

TSG-NEW-R-150

Φ1.50mm

3561070

3562028

TSG-NEW-R-160

Φ1.60mm

3561071

3562029

TSG-NEW-R-170

Φ1.70mm

3561072

3562030

TSG-NEW-R-180

Φ1.80mm

3561073

3562031

TSG-NEW-R-190

Φ1.90mm

3561074

3562032

TSG-NEW-R-200

Φ2.00mm

3561075

3562033

TSG-NEW-R-210

Φ2.10mm

3561076

3562034

TSG-NEW-R-220

Φ2.20mm

3561077

3562035

TSG-NEW-R-230

Φ2.30mm

3561078

3562036

TSG-NEW-R-240

Φ2.40mm

3561079

3562037

TSG-NEW-R-250

Φ2.50mm

3561080

3562038

TSG-NEW-R-260

Φ2.60mm

3561081

3562039

TSG-NEW-R-270

Φ2.70mm

3561082

3562040

TSG-NEW-R-280

Φ2.80mm

3561083

3562041

TSG-NEW-R-290

Φ2.90mm

3561084

3562042

TSG-NEW-R-300

Φ3.00mm

3561085

3562043
